USA Security Systems

LM50XC

Kowa LM50XC 4/3" 50mm 20MP Lens Compatible with Sony Sony IMX387, Sony IMX540 sensors and many more

Kowa LM50XC 4/3" 50mm 20MP Lens Compatible with Sony Sony IMX387, Sony IMX540 sensors and many more

SKU:LM50XC

Regular price $867.00 USD
Regular price Sale price $867.00 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

Discover the Power of Kowa LM50XC 4/3" 50mm MP Lens

USA Security Systems Inc. presents Kowa, a renowned brand delivering precision optics for industrial and machine vision applications. The Kowa LM50XC 4/3" 50mm MP Lens epitomizes excellence in image capture, offering unparalleled clarity and resolution. Engineered for sensors with a pixel size of 3.0μm or more, this C-mount lens is optimized for compatibility with various sensors including Sony IMX387 and Sony IMX540. With a focal length of 50mm and a maximum aperture of f/2, it ensures exceptional image quality across diverse industrial environments.

The Kowa LM50XC lens boasts a rugged design suitable for challenging conditions, with manual iris control allowing precise adjustments for optimal image acquisition. Its broad wavelength range from 380nm to 1000nm ensures versatility in imaging tasks. Whether in manufacturing, inspection, or surveillance, this lens excels, delivering sharp images with minimal distortion.

Experience unrivaled clarity and precision in industrial imaging with Kowa LM50XC 4/3" 50mm MP Lens. Maximize your machine vision applications today with USA Security Systems Inc.

Features:

  • High-resolution 50mm MP lens
  • Compatible with 4/3" sensors
  • Manual iris control for precision
  • Broadband coating for versatile imaging
  • Rugged design for industrial environments

Applications:

  • Manufacturing inspection
  • Quality control
  • Surveillance systems
  • Robotics guidance
  • Object recognition

LM50XC Spec Sheet

Focal Length (mm) 50mm
Image Size (mm)

18.4×13.8 (Φ23)

Iris Range F2.0~F22
Focusing Range (m)
.3~∞
Control
Iris: Manual
Focus: Manual
Shooting Range at M.O.D. (mm)
100.2(H)×75.5(V)
Angle of View (Degrees)
4/3": 20.6×15.7
1": 14.6×11.0
2/3": 10.1×7.6
Resolution (Center, Corner)
160lp/mm, 80lp/mm
TV Distortion (%)
0.80
Back Focus in Air (mm)
21.6
Mount
C-Mount
Filter Thread (mm)
M37.5×P0.5
Size (mm)
Φ47×78
Weight (g) 235
Temperature Range −10°C~+50°C
