Marshall Electronics CV570 Miniature POV Camera NDI|HX3 and HDMI

Marshall Electronics CV570 Miniature POV Camera: Exceptional Performance for Industrial and Machine Vision Applications

The Marshall CV570 Miniature POV Camera stands out in the realm of industrial and machine vision applications, boasting a next-generation Sony sensor with over 2.13 million pixels and a square pixel array. Its durable aluminum alloy body ensures resilience in various working environments. With exceptional low-light sensitivity and refined remote adjust capability, this camera delivers rich, color-accurate video even in challenging lighting conditions. The CV570 offers flexible connectivity options, including NDI|HX3 workflows, HDMI, and standard IP with SRT streaming. Its interchangeable M12 lenses provide adaptability for diverse POV environments, ensuring focus from near contact to infinity.

Featuring 10-bit 4:2:2 video performance, the CV570 supports full HD resolutions up to 1080p, 720p, and 1080i, with a wide range of selectable framerates. With features like simultaneous HDMI output and support for streaming codecs like SRT, RTSP, RTMP, and HEVC, this camera is suitable for various broadcast and proAV applications worldwide.

Features:

• Next-generation Sony sensor with over 2.13 million pixels
• Durable aluminum alloy body
• Exceptional low-light sensitivity
• Interchangeable M12 lenses
• NDI|HX3 workflows, HDMI, and standard IP with SRT streaming
• 10-bit 4:2:2 video performance
• Simultaneous HDMI output
• Support for streaming codecs like SRT, RTSP, RTMP, and HEVC
• Flexible power options: 7~15V flexibility or PoE over Cat cable

Applications:

• Quality control and inspection
• Robotics guidance
• Object tracking and recognition
• Automated assembly
• Surveillance and security
• Remote monitoring and inspection
• Industrial automation
• Medical imaging
• Traffic monitoring and management
• Agricultural monitoring and analysis

Download Data Sheet
